Model
|
PS3N
|
PS3N-SR
|
PS3F
|
PS3F-SR
|
Power supply
|
AC/DC100 to 200V ±10% 50/60Hz
|
Power consumpion
|
10W Max.
|
Input
|
NPN open collector input
Input mode: L operation
|
NPN open collector input
Input mode: H/L switing operation
Min. response input time: 20µs
|
Oparation mode
|
AND operation
|
AND operation, CLOCK AND operation
(ON-delay, OFF-delay, One-shot, No-timer)
Timer: 0.1 to 1s, 1 to 10s
|
Output mode
|
Relay contact output 1C
Rating: 2A (AC250V)
Resistance load
|
Triac output 1a
Photo coupler type
Zero-class type
Load voltage:
AC75V Min., 250V Max.
Load current:
10mA Min., 2A Max.
Stay ON voltage: 1.5V Max
|
• Relay contact output 1C
Rating: 2A (AC250V)
Resistance load
• NPN open collector output
Rating: 100mA (DC30V)Max.
Stay ON voltage: 1V Max.
|
• Triac output 1a
Photo coupler type
Zero-class type
Load voltage:
AC75V Min., 250V Max.
Load current:
10mA Min., 2A Max.
Stay ON voltage: 1.5V Max.
• NPN open collector output
Rating: 100mA (DC30V)Max.
Stay ON voltage: 1V Max.
|
Sensor supply source
|
DC 12V ±10% 200mA Max. (Circuit protection built-in)
|
Response time
|
5ms Max.
|
12ms Max.
|
• At relay output, 5ms Max.
• NPN open collector output
at ON: 20µs Max.
at OFF: 50µs
|
• At triac output, 12ms Max.
• NPN open collector output
at ON: 20µs Max.
at OFF: 50µs
|
Indicators
|
POWER: Power (Green LED)
OUTPUT: Operation (Green LED)
|
Volume
(VR)
|
–
|
TIME: Timer adjustment volume
in the 0.1 to 1s or 1 to 10s range variable
|
Switch
(SW)
|
–
|
INPUT1: Input mode: H/L switch built-in
INPUT2
AND(Lo-Hi)AND: or CLOCK AND switch built-in
TIME: Timer time swith built-in
1s side -0.1 to 1s variable
10s side -0.1 to 10s variable
TIMER: Timer operation swith built-in
|
Material
|
ABS resin
|
Connection
|
Terminal block type (screw: M3.5, width: 8.1mm)
|
Mounting
|
DIN rail (35mm), Threadably mounted type
|
Weight
|
120g Max.
|
150g Max.
|
