Full Description TAKEX Sensor : Light Curtain Sensor SSP-T200 series Synchronization line is unnecessary. Robust metal enclosure and yet super slim type of slightly 13mm 2 groups of eye-friendly and large-sized job indicators Fault indicator Lighting operation is selectable Common use for NPN/PNP NPN or PNP can be changed by a switch inside of the sensor unit, which contributes to reduction of product inventory. Model No. Set model SSP-T205 SSP-T210 SSP-T213 SSP-T216 Transmitter SSP-TL205 SSP-TL210 SSP-TL213 SSP-TL216 Receiver SSP-TR205 SSP-TR210 SSP-TR213 SSP-TR216 Detection Through-beam Range 2 m (Max.) Detection object ø35 mm (Min.)Opaque object No. of optical axis 5 10 13 16 Detection width 100mm 225mm 300mm 375mm Optical axis pitch 25 mm Power supply 12 to 24VDC ±10 %, Ripple 10 % (Max.) Current consumption(Max) 130mA 140mA 150mA 155mA Output mode NPN / PNP output selectableRating : Current 50mA (30VDC)Max. Residual voltage2V or less Operation mode Light-on/Dark-on selectable Job indicator input Non-contact or contact in put Response time Standard Light_on: 35 ms Light_on: 68 ms Light_on: 70 ms Light_on: 94 ms Dark_on: 25ms Dark_on: 42ms Dark_on: 42ms Dark_on: 58ms Interference protection Light_on: 45 ms Light_on: 84 ms Light_on: 88 ms Light_on: 116 ms Dark_on: 28ms Dark_on: 52ms Dark_on: 54ms Dark_on: 72ms Light source Infrared LED, Wave-length 880nm Indicator Transmitter Power indicator (Green LED) / Job indicator (Green LED) Receiver Stability indicator (Green LED)/ Dark indicator(Orange LED)Unstability indicator (Green LED)/ Job indicator(Green LED) Job indicator Lights/Flickering selectable / Lighting speed switch (Fast/Slow) Short circuit protection Built-in Interference protection Built-in (within 2 sets) Material Enclosure: Aluminum,Lens : Polycarbonate,End plate: Resin Wiring Flying lead(Outer dia.F4.1) 2 m length Transmitter:0.2mm2 × 3 cores(Gray) Receiver :0.2mm2 × 4 cores(Black) Weight (Max.) Transmitter 105g 160g 195g 225g Receiver 110g 170g 205g 240g Incidental function Automatic sensitivity correction function Ambient light 10,000 lx (Max.) Operating temperature 10 to 55°C (Storage: 25 to 70°C) Operating humidity 35 to 85 %RH Enclosure protection IP 62 Vibration resistance 10Hz to 55Hz, 1.5mm Amplitude,2 hours, X,Y and Z directions Shock resistance 500 m/s 3 times X,Y and Z directions Dielectric strength 1,000VAC for 1 minute Insulation resistance Min.20 MΩ (at 500VDC) Related Product10/20/40mm Pitch Light Curtain Sensors SS10/20/40January 10, 2020Cross Ray Sensors SSC-T800January 10, 2020Slim Type Light Curtain Sensors ESNJanuary 10, 2020Slim Type Light Curtain Sensors JSJanuary 10, 2020
